SKF · GENUINEB-2222 EK
Ball Bearing 2222 EK
SKF designation 2222 EK
Price
Quoted live · in 24h
1
Add to your quote basket — no payment now. We reply with a firm price and dispatch ETA within 24h. Pay by M-Pesa, mobile money or LPO once you approve.
Live stock · East Africa network
as of 2026-07-17—
NBO
Nairobi
✓
KLA
Kampala
—
DAR
Dar es Salaam
—
MWZ
Mwanza
Available — transfers from the network
In stock at Kampala. We transfer across the network and confirm a firm ETA with your quote in under 24h.
§02 · Overview
Self-aligning ball bearings have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring. They are insensitive to angular misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection.
§03 · Datasheet
Technical specificationSKF verified21 fields
Self-aligning ball bearing
- Accommodate static and dynamic misalignment
- Excellent high-speed performance
- Excellent light load performance
- Low friction
BWidth53mm
DOutside diameter200mm
dBore diameter110mm
D₁Shoulder diameter outer ring(≈)174.3mm
d₁Shoulder diameter inner ring(≈)138.5mm
r₁,₂Chamfer dimension(min.)2.1mm
Load ratings3
CBasic dynamic load rating124kN
C₀Basic static load rating52kN
PᵤFatigue load limit2.12kN
Speed2
Limiting speed4,300r/min
Reference speed6,000r/min
Calculation factors6
eLimiting value0.28
Y₀Calculation factor2.5
Y₁Calculation factor2.2
Y₂Calculation factor3.5
kᵣCalculation factor0.04
Permissible angular misalignment2.5°
Mounting / abutment3
DₐAbutment diameter housing(max.)188mm
dₐAbutment diameter shaft(min.)122mm
rₐFillet radius(max.)2mm
Other1
CylindricalBore type
